Q. Can you extrude a helix?
How can I extrude circle along a helix? You can’t.
Q. Can arc be extruded in AutoCAD?
Select the lines and arcs that would make up one plane of your 3D solid then type region on the command line. The lines and arcs are then replaced by a “region” object which can then be extruded to form a 3D solid.
Q. How do you use extrusion in AutoCAD?
To Create a 3D Solid by Extruding
- If necessary, on the status bar click Workspace Switching and select 3D Modeling. Find.
- Click Solid tab > Solid panel > Extrude. Find.
- Select the objects or edge subobjects to extrude.
- Specify the height.
Q. What Cannot be extruded in AutoCAD?
2D polylines with crossing segments cannot be extruded. Thickness and width are ignored. The extrusion extends from the center line.
Q. How do you use helix in AutoCAD?
A helix is an open 2D or 3D spiral.
- Click Home tab Draw panel Helix. Find.
- Specify the center point for the base of the helix.
- Specify the base radius.
- Specify the top radius or press Enter to specify the same value as the base radius.
- Specify the height of the helix.
Q. What is helix tool?
Helix is an incident response and computer forensics toolkit based on the popular Knoppix Live bootable CD. It contains dozens of tools for incident response on Windows and Linux systems.
Q. What can you do with a helix in AutoCAD?
Creates a 2D spiral or 3D spring. Use a helix as a sweep path for the SWEEP command to create springs, threads, and circular stairways. The following prompts are displayed. Sets the center of the helix base point. Specifies the radius of the base of the helix.
Q. How do you extrude an object in AutoCAD?
Specifies the extrusion path based on a selected object. The path is moved to the centroid of the profile. Then the profile of the selected object is extruded along the chosen path to create solids or surfaces. Note: Select face and edge subobjects by pressing Ctrl while you select them.
Q. How do you extrude a Polyline in AutoCAD?
Press Ctrl and use the gizmo to change the location of the edge. 2D polylines with crossing segments cannot be extruded. Thickness and width are ignored. The extrusion extends from the center line. The following prompts are displayed. Specifies the objects to extrude. Note: Select face and edge subobjects by pressing Ctrl while you select them.
Q. What’s the difference between sweep and extrude in AutoCAD?
The SWEEP command works with few differences as compared to the EXTRUDE command. It helps obtain 3D object from 2D object, just by indicating the path through which the 2D object is going to SWEEP to create the 3D object.
