Note the neutral formula. If A, B and C are the three phase currents, the formula to find the neutral current is the square root of the following: (A^2 + B^2 + C^2 – AB – AC – BC).

If the load is unbalanced, there is a neutral or imbalance current flow. Current imbalance can cause voltage unbalance and if the system is not monitored well for neutral conductor, probability of failure will be high.

The purpose of the neutral wire is to carry back the unbalance of the load. So in a normal (US) house of 120/240 volts single phase, if one of your hot wires is carrying 30 amps and the other is carrying 23 amps, then the neutral will have to be able to carry 7 amps to keep the system balanced.

With a regular 120-volt AC circuit, the neutral wire provides a return path to earth ground. If the neutral wire disconnects, it would stop the flow of the electricity and break the circuit. The role of the neutral wire is to provide this path to the electrical panel to complete the circuit.

How to calculate voltage unbalance

1. Determine the voltage or current average.
2. Calculate the largest voltage or current deviation.
3. Divide the maximum deviation by the average voltage or current and multiply by 100 % unbalance = (Max deviation from average V or I/average V or I) x 100.

For a three-phase supply, current unbalance is defined as the maximum deviation of any current phase from the average current, divided by the average current, often expressed as a percentage. In these cases, the current unbalance is usually higher than the voltage unbalance.

Since the neutral wire completes and electrical circuit (in terms of alternating current) it carries the same current as the live or phase wire tracing back to the generator, however, it’s potential to earth is nearly 0V.

The neutral carries current if the loads on each phase are not identical. In some jurisdictions, the neutral is allowed to be reduced in size if no unbalanced current flow is expected. If the neutral is smaller than the phase conductors, it can be overloaded if a large unbalanced load occurs.

The current in the neutral wire between your house and the power company’s transformer will depend on how the loads in your house are balanced between the two “hot” wires. The neutral carries the difference in amperage between the Black and red if they are on the 2 different legs in the panel.

We can remove the neutral conductor or wire. However, to achieve this, the load connect to the circuit must be identical. The load must be balanced. In an ideal situation or in the situation where load is equal, current flowing through neutral conductor is always Zero.
