Flooding is a phenomenon by which gas moving in one direction in the packed column entrains liquid moving in the opposite direction in the packed column.

Originally Answered: what is loading point in packed column ? Loading point of a column is when the gas velocity is high enough to restrict the flow of liquid. After this point, the pressure drops at a much faster rate till another point, known as the flooding point, when all the liquid is carried away by the gas.

iii) % of flooding can be calculated by the ratio of normal vapour mass velocity (G’) to flooding vapour mass velocity (G) for a given column diameter. It is recommended that new towers be designed at a maximum of 80 % of flood. A higher percentage flood of around 85% may be used in tower revamps.

Building upon Ralph’s answer, as he says, loading refers to the vapor and liquid traffic passing through a packed bed or tray. Also at high pressure drop across tray it is possible to back the liquid level in the downcomer and flood the tray above. This is called downcomer backup flooding.

Point c is known as the loading point, as liquid starts to accumulate (load) in the packings. Point e is known as the flooding point. The gas velocity at this point is known as the flooding velocity (limiting velocity). Points to note : – at constant liquid rate, gas pressure drop increases with gas velocity.

Jet flooding, also called entrainment flooding, is caused by massive entrainment of liquid to the tray above. The recirculation of entrained liquid decreases efficiency by moving heavier components up the column, contaminating lighter products.

In distillation column, liquid flows in downward direction by gravitational force but it flows against the pressure. When liquid flows from one tray to next below tray, it flows from lower pressure to higher pressure. When the liquid level in downcomer on any tray rises above the weir, it is called downcomer flooding.

Jet Flood: Jet flood rating should be limited to 85% of flood to avoid the possibility of flooding and/or inefficient operation. Increasing tower diameter, active area and/or tray spacing can be used to reduce the jet flood rating. Downcomer Flood: Downcomer rating should be limited to 85% of flood.

The HETP is the theoretical link between the Plate Theory and the Rate Theory as the HETP is numerically equal to the variance per unit length of the column as determined from the Rate Theory.

In industrial practice, the HETP concept is used to convert empirically the number of theoretical trays to packing height. Most data have been derived from small-scale operations and they do not provide a good guide to the values which will be obtained on full-scale plant.

Decreasing particle size thus is a useful method for improving column efficiency and providing better separations. changing to particles that are half as big, while keeping the column length the same, will double the performance, but increase the required pressure by a factor of four.

The number of theoretical plates is often used to establish the efficiency of a column. Plate numbers range from 100 to 106. The more theoretical plates available within a column, the more equilibrations between the stationary and mobile phases are possible and the better the quality of the separation.

Sephadex is a cross-linked dextran gel used for gel filtration. The name is derived from separation Pharmacia dextran. It is normally manufactured in a bead form and most commonly used for gel filtration columns. By varying the degree of cross-linking, the fractionation properties of the gel can be altered.

gel filtration medium

Sephadex® G-75 is a gel filtration media used in gel filtration chromatography and protein chromatography. It has been used for desaltation process to study the production, purification, and immobilization of l-asparaginase II (ASNase II) in chitosan nanoparticles (CSNPs).

Gel filtration based on Sephadex enables group separation of biomolecules that are above the exclusion limit of the medium, from contaminants such as salts, dyes, and radioactive labels. Sephadex is prepared by cross-linking dextran with epichlorohydrin.

If a Kav is calculated to be less than 0, the column likely has developed channels and should be repacked. If a Kav is calculated to be greater than 1, some kind of adsorption is indicated.

Desalting is sometimes called group separation mode. In fractionation by size, all the molecules to be separated are below the size exclusion limit of the column, and are retained by the column. The amount of retardation of each molecule is related to its size (and shape).

Select a column with a bed height providing the required resolution. A bed height between 30 and 100 cm is recommended for preparative separation. Select a column size appropriate for the volume of sample that needs to be processed. Select the highest flow rate that maintains resolution and minimizes separation time.

Smaller molecules experience a more complex pathway (like a maze) to exit the particle than do larger molecules. Because molecules that have a large size compared to the pore size of the stationary phase have very little entrance into the pores, these larger sized molecules elute first from the column.

In SEC, the exclusion limit is the molecular weight at the upper limit of a column’s working range, beyond which molecules are too large to get trapped in the stationary phase and will elute together in the void volume of the column. Many SEC packings are referred to by their exclusion limit.

Media for gel exclusion chromatography

	lower limit	upper limit
Sephadex G-50	1.5	30
Sephadex G-75	3	80
Sephadex G-100	4	150
Sephadex G-150	5	300

Molecules larger than the pore size pass straight through (are excluded). This is called the exclusion limit. Conversely, molecules below a certain size completely penetrate the pores and tend to elute almost in the same position. This is called the permeation limit.

With gel filtration, buffer salts and other small molecules within the substance will slide through the resin beads. Faster molecules within the solution will be separated from the smaller and slower molecules, thereby separating the larger molecules out.

Sepharose is a tradename for a crosslinked, beaded-form of agarose, a polysaccharide polymer material extracted from seaweed. Its brand name is a portmanteau derived from Separation-Pharmacia-Agarose. A common application for the material is in chromatographic separations of biomolecules.
