The switch causes a break in the circuit” is the reason why a light goes out when you turn off the wall switch. The electrons can no long move towards the lightbulb.

When you move the switch to shut off your flashlight, you disconnect the wires that run from the battery to the light bulb. When you turn off your flashlight, you put the switch in what is called the open position. With the switch in the open position, you have a disconnected wire, and no current can flow.

We see the photons reflecting off the surfaces around us, our retinas absorb those photons and translates it into sight. When we turn the light off we are effectively reducing the intensity of high-energy photons in the system, so what reaches our eyes are outside the visible spectrum.

The power switch is a rocker switch and it has two symbols on the face: “O” and “—“. They are the International symbols for power “On” and power “Off”. “O” means the power is OFF and “–“means the power is ON.

All the electric appliances stop working in a house when the main switch is put off because the electric circuit (the path where the electricity travels) gets opened. A circuit needs to be closed in order for current to flow through it and thus all electric appliances to work.

On switching off the mains switch of the house, live and neutral wires are disconnected in order to break the circuit.

Electrical appliances are connected in a parallel arrangement in a house circuit because: Each appliance gets full voltage as resistance in a parallel arrangement is low. If one appliance fuses, it does not affect the working of other appliances. We can use one appliance without using other appliances.

Staircase wiring connection using 2 two way switches and intermediate switch to control a light point from three different places.

8

A 3-way switch is one that allows you to control a ceiling light (or other electrical fixture) from two separate locations. Common scenarios would be 3-way switches located at both the top and bottom of a stairway, or having 3-way switches next to doors in a room with two entry points.

In terms of home electrical wire, you’ll usually be working with 12 or 14-gauge wire. But for appliances, you’ll be using 10, 8, or 6 gauge. Things like stoves, water heaters, dryers, and air conditioning units use these larger gauges because they require a lot of amperages.

The most common type of wiring in modern homes is in the form of nonmetallic (NM) cable, which consists of two or more individual wires wrapped inside a protective plastic sheathing. NM cable usually contains one or more “hot” (current-carrying) wires, a neutral wire, and a ground wire.

The “common” is the “neutral” or “ground” wire, depending on the type of circuit. In normal US residential wiring, you’ll have a black “hot” wire, a white “neutral” or “common” wire, and a green or bare “ground” wire.
