There are four general wing shapes that are common in birds: Passive soaring, active soaring, elliptical wings, and high-speed wings. feathers that spread out, creating “slots” that allow the bird to catch vertical columns of hot air called “thermals” and rise higher in the air.

In general, the operation for which an airplane is designed determines the shape and design of its wings. If the airplane is designed for low-speed flight, a thick airfoil is most efficient, whereas a thin airfoil is more efficient for high-speed flight.

Airfoil Three

The reason for providing the wing incidence is given below. For the economy in fuel consumption, the drag should be minimum during cruise. The fuselage has a minimum drag when its angle of attack is zero. However, during cruise, the wing should produce sufficient lift to support the weight of the airplane.

High wing airplanes are very stable at slower speeds, meaning they can right themselves quickly if they encounter turbulence while travelling slowly. Low wing airplanes are more stable than mid-wing airplanes, but not as much as high-wing airplanes. They are also more maneuverable than high-wing airplanes.

A larger horizontal tail will give a more statically stable airplane than a smaller tail (assuming, as is the normal case, that the horizontal tail lies aft of the center of gravity of the airplane).

The low wing makes an obvious place to attach the main landing gear, usually resulting in a wider stance that improves stability in taxiing. A low center-of-gravity on the ground makes it easier to negotiate strong winds with the wide gear.

What is a low wing aircraft? The wings on a low wing aircraft are mounted lower than halfway up the fuselage. Expect to see some dihedral (upward angling of the wing tips compared to the wing root) to improve lateral stability. The Piper Cherokee is one of the most common low wing general aviation planes.

For that reason all modern fighter aircraft position the horizontal tail as low as practical. Or, in other words, the F-16 wing can have zero dihedral because the horizontal tail in combination with the ventral fins reduces the rolling moment of the vertical tail in a sideslip to the desired value.

In aerodynamics, wing loading is the total mass of an aircraft or flying animal divided by the area of its wing. Consequently, faster aircraft generally have higher wing loadings than slower aircraft. This increased wing loading also increases takeoff and landing distances.

Keywords : Choice of wing loading based on considerations of landing field length, prescribed flight speed, absolute ceiling, maximum rate of climb, range, take-off balance field length, specific excess power, sustained turn rate and turbulence.

The relationship between wing area and body weight is given in kilograms per square metre (or grams per square centimetre). To calculate wing loading, divide the mass of the bird or plane by the total area of the upper surface of its wings: wing loading = body mass (kg)/wing area (m2).

To being, one must take a look at the evaluation of three primary loads that act on the aircraft wing: aerodynamic lift, load due to wing structure weight, and load due to the weight of the fuel contained in the wing.

There are four main load sources acting on an aeroplane – aerodynamic forces, inertia, ground reactions and thrust. The goal of the current work is it to determine its critical combinations.

The four forces acting on an aircraft in straight-and-level, unaccelerated flight are thrust, drag, lift, and weight.

The wings are prevented from folding over the fuselage by the resisting strength of the wing structure. The bending action creates a tension stress on the bottom of the wings and a compression stress on the top of the wings.

The term ”bearing stress” denotes the value obtained by dividing the force acting between two surfaces by the component of the area of contact normal to the force. A localized stress condition may not be directly associated with failure.

tail assembly

cantilever wing: translation. A wing that uses no external struts or bracing. All support is obtained from the wing itself. The wing spars are built in such a way that they carry all the torsion and bending loads.

A cantilever is a beam supported only at one end, with load carried over the overhanging. This is in contrast to a simply-supported beam, which is supported at both ends. Cantilevers provide a clear space underneath the beam without any supporting columns or bracing.

In the cantilever wing one or more strong beams, called spars, run along the span of the wing. The end fixed rigidly to the central fuselage is known as the root and the far end as the tip. In flight, the wings generate vertical lift and the spars carry this load through to the fuselage.

[click image to enlarge] Often wings are of full cantilever design. This means they are built so that no external bracing is needed. Other aircraft wings use external struts or wires to assist in supporting the wing and carrying the aerodynamic and landing loads.

A cantilever beam is a member with one end projecting beyond the point of support, free to move in a vertical plane under the influence of vertical loads placed between the free end and the support.

A cantilever is a protruding beam that’s supported on only one side. Rooted in physics and structural design, a cantilever can be a stunning architectural element or just a clever way to add a little more light to a room.
